Sandstone Cutting Machine for Quarrying & Block Cutting

Name: Sandstone Cutting Machine for Quarrying & Block Cutting
Brand: DINOSAW
SKU: SSQJ-1400
Availability: InStock

SSQJ-1400

The DINOSAW sandstone cutting machine integrates horizontal and vertical saws for dualdirection cutting with speeds of 10-45 meters/minute. Ideal for construction material production, it delivers superior material yield with 35% less waste compared to traditional extraction methods. This machine excels at quarrying sandstone, limestone and laterite into blocks. The automated operation reduces labor requirements by 60% while maintaining consistent quality.

Compatible Materials & Products

Mechanical extraction of dimensional blocks from sandstone, limestone, laterite and travertine benches.

Specs and options

Specifications customizable upon request.

Model	Unit	SSQJ-1400
Vertical	kw	75
Horizontal	kw	45
Rail	kw	5.5
Moving speed (forward &backward)	m/min	10 - 45
Max distance of cylinder lifting	mm	700
Max cutting depth	mm	520
Diameter of the vertical	m	1330
Diameter of the horizontal	mm	600
Thickness	mm	11.5

The SSQJ-1400 works directly on the quarry face: a 75 kW vertical blade opens the face and sides, a 45 kW horizontal blade undercuts the base, and the rail-mounted frame travels the bench — mechanical block extraction from stratified sandstone, limestone, laterite and travertine without blast damage.

Real Cutting Performance & Key Metrics

Vertical Cutting Power

The 75 kW vertical motor drives the 1330 mm blade through full 520 mm depth passes in sandstone and limestone benches.

Horizontal Undercutting

The 45 kW horizontal blade with 600 mm diameter undercuts the bench, freeing blocks at the base without wedge-and-feather work.

Depth per Vertical Pass

A 520 mm cutting depth lets the blade follow usable bedding thickness in stratified stone instead of building the same cut from repeated shallow passes.

Two-Direction Quarry Cutting

The 1330 mm vertical blade opens the face and side cuts while the 600 mm horizontal blade undercuts the block base: the same rail-mounted machine completes the critical faces that define the extracted block, replacing hand plugging and wedge work at the quarry bottom.

520 mm Full-Depth Pass

A 520 mm cutting depth lets the blade follow usable bedding thickness in sandstone and limestone: thick blocks extract along the stone's natural layers instead of through them, protecting corners and usable thickness.

Rail-Mounted Quarry Travel

The machine moves along the working face on its own rail system at 10–45 m/min: one position covers a long bench section, and relocation follows the quarry's advance without civil works.
